JH25-250
WORLD
-strong body, steel welded, optimized design, temperature treatment
-double crank type, good synchronization
-better load-deflection resistance capacity
Press type: double crank power press
Clutch type: wet type pneumatic clutch with brake
PLC brand: Panasonic
HMI: touch sreen in English versions
Press tonnage: 250ton
Stroke length: 280mm
Stroke speed: 20-35spm
Bolster size: 2700x920mm
Ram plate size: 2100x700mm
Main motor: Siemens brand, 30kw
Machine weight: 35ton
-strong body, steel welded, optimized design, temperature treatment
-double crank type, good synchronization
-better load-deflection resistance capacity
Press type: double crank power press
Clutch type: wet type pneumatic clutch with brake
PLC brand: Panasonic
HMI: touch sreen in English versions
Press tonnage: 250ton
Stroke length: 280mm
Stroke speed: 20-35spm
Bolster size: 2700x920mm
Ram plate size: 2100x700mm
Main motor: Siemens brand, 30kw
Machine weight: 35ton
ITEM | CODE | UNIT | JH25-250 | |
Nominal Capacity | Pe | KN | 2500 | |
Stroke Length | S | mm | 280 | |
Rated Tonnage Point | mm | 7 | ||
Stroke Speed | Fixed | spm | 30 | |
Variable (optional) | spm | 20-35 | ||
Max. Die Shut Height | H2 | mm | 550 | |
Die Shut Height Adjustment | t | mm | 120 | |
Throat Depth | G | mm | 470 | |
Distance Between Uprights | N | mm | 2190 | |
Table Size | F-B | D | mm | 920 |
L-R | C | mm | 2700 | |
Thickness | H3 | mm | 180 | |
Slide Bottom Size | F-B | b | mm | 700 |
L-R | a | mm | 2100 | |
Table Surface Height | H1 | mm | 1225 | |
Overall Dimensions | F-B | A | mm | 2700 |
L-R | B | mm | 2850 | |
Height | H | mm | 4400 | |
Motor Power | KW | 30 | ||
Air Pressure | Mpa | 0.5 | ||
Weight (approximate) | kg | 35000 |
