1530
Plasma cutting machine with table size 1500x3000mm. China LGK 63A plasma source, independent control cabinet. Automatic torch height controller, Starcam software, 2GB processing file.
Model | 1530 63A Plasma cutting machine (high configuration |
X,Y working area | 1500*3000mm |
Z working area | 150mm |
Packing dimension | 2280mm*3950mm*1850mm |
Lathe bed | Very thick steel structure |
Machine Power | 8.5kw |
Working voltage | 380V three phase 60hz |
Reposition precision | 0.02mm |
Processing precision | 0.1mm |
Maximum cutting speed | 12000mm/min |
Torch Height control mode | Automatic |
Cutting thickness | Max 12mm carbon steel |
Plasma power supply | LGK63A |
Control system | STARfire |
Motors | Stepper motor |
Software | Starcam |
Weight | 1600KG |
Plasma Air Pressure | Max.0.8Mpa |
Working Temperature | -10°C-60°C. Relative Humidity, 0-95%. |
LCD Display Dimension | 7 Inches |
Plasma cutting machine with table size 1500x3000mm. China LGK 63A plasma source, independent control cabinet. Automatic torch height controller, Starcam software, 2GB processing file.
Model | 1530 63A Plasma cutting machine (high configuration |
X,Y working area | 1500*3000mm |
Z working area | 150mm |
Packing dimension | 2280mm*3950mm*1850mm |
Lathe bed | Very thick steel structure |
Machine Power | 8.5kw |
Working voltage | 380V three phase 60hz |
Reposition precision | 0.02mm |
Processing precision | 0.1mm |
Maximum cutting speed | 12000mm/min |
Torch Height control mode | Automatic |
Cutting thickness | Max 12mm carbon steel |
Plasma power supply | LGK63A |
Control system | STARfire |
Motors | Stepper motor |
Software | Starcam |
Weight | 1600KG |
Plasma Air Pressure | Max.0.8Mpa |
Working Temperature | -10°C-60°C. Relative Humidity, 0-95%. |
LCD Display Dimension | 7 Inches |
