Y32-315
-three-beams four-columns structure
-easy operation and maintenance
-capacity: 3150kN
-table size, stroke length, open height: cusomizable
-ejection cylinder under the table: optional
No. | Parameter | Unit | Spec. | |
1 | Nominal Force | kN | 3150 | |
2 | Pusthup Pressure | kN | 600 | |
3 | Max.hydraulic ic pressure | MPa | 25 | |
4 | Stroke of knock-out cylinder | mm | 300 | |
5 | Stroke of slide | mm | 800 | |
6 | Max. Distance from down-level of slide to work table | mm | 1250 | |
7 | Speed of slide | Empty descending | mm/s | 250 |
pressing | mm/s | 7-20 | ||
return | mm/s | 280 | ||
8 | Effective area of work table | L-R | mm | 1200 |
F-B | mm | 1000 | ||
9 | Motor Power | kW | 18.5 | |
-three-beams four-columns structure
-easy operation and maintenance
-capacity: 3150kN
-table size, stroke length, open height: cusomizable
-ejection cylinder under the table: optional
No. | Parameter | Unit | Spec. | |
1 | Nominal Force | kN | 3150 | |
2 | Pusthup Pressure | kN | 600 | |
3 | Max.hydraulic ic pressure | MPa | 25 | |
4 | Stroke of knock-out cylinder | mm | 300 | |
5 | Stroke of slide | mm | 800 | |
6 | Max. Distance from down-level of slide to work table | mm | 1250 | |
7 | Speed of slide | Empty descending | mm/s | 250 |
pressing | mm/s | 7-20 | ||
return | mm/s | 280 | ||
8 | Effective area of work table | L-R | mm | 1200 |
F-B | mm | 1000 | ||
9 | Motor Power | kW | 18.5 | |
