GL
-Optimized structure, uncoiling and straightening machines are combined.
-All rollers are heat treatment and chrome plated. Surface hardness HRC60-62.
-Straightener roller gap is adjusted by worm-gear system, with 4pcs pressing pneumatic cylinders.
-Standard with oil hold arm (except GL-200A).
-Standard with inverter for adjustable speed 1-15m/min.
-Manual expansion system is standard, hydraulic expansion is optional.
-Standard with 4pcs A arms to fix the coil on the mandrel.
-CE mark
Model No | GL-200A | GL-300A | GL-400A | GL-500A | GL-600A |
Material thickness | 0.5-4.5mm | 0.5-4.5mm | 0.5-4.5mm | 0.5-4.5mm | 0.5-4.5mm |
Material width | 200mm | 300mm | 400mm | 500mm | 600mm |
Straightener roller | Upper 3/lower 4 | Upper 3/lower 4 | Upper 3/lower 4 | Upper 3/lower 4 | Upper 3/lower 4 |
Feeding roller | 4 sets | 4 sets | 4 sets | 4 sets | 4 sets |
Speed | 1-15m/min | 1-15m/min | 1-15m/min | 1-15m/min | 1-15m/min |
Straightening roller gap adjustment | synchronous worm gear device | synchronous worm gear device | synchronous worm gear device | synchronous worm gear device | synchronous worm gear device |
Coil I.D. | ∅450-530mm | ∅450-530mm | ∅450-530mm | ∅450-530mm | ∅450-530mm |
Coil O.D. | ∅1200mm | ∅1200mm | ∅1200mm | ∅1200mm | ∅1200mm |
Coil weight | 1000kg | 1000kg | 2000kg | 2000kg | 3000kg |
Coil press arm | optional | standard | standard | standard | standard |
Expansion method | manual | manual | manual | manual | manual |
Motor Power | 1.5kW | 1.5kW | 2.2kW | 3.75kW | 3.75kW |
Thickness | GL-200A | GL-300A | GL-400A | GL-500A | GL-600A |
0.5-1.0mm | 200 | 300 | 400 | 500 | 600 |
1.5mm | 200 | 300 | 400 | 500 | 600 |
2.0mm | 200 | 300 | 380 | 450 | 530 |
2.5mm | 200 | 250 | 300 | 380 | 430 |
3.0mm | 200 | 220 | 280 | 320 | 360 |
3.5mm | 150 | 180 | 240 | 280 | 300 |
4.0mm | 120 | 140 | 190 | 230 | 260 |
4.5mm | 90 | 100 | 140 | 190 | 200 |
-Optimized structure, uncoiling and straightening machines are combined.
-All rollers are heat treatment and chrome plated. Surface hardness HRC60-62.
-Straightener roller gap is adjusted by worm-gear system, with 4pcs pressing pneumatic cylinders.
-Standard with oil hold arm (except GL-200A).
-Standard with inverter for adjustable speed 1-15m/min.
-Manual expansion system is standard, hydraulic expansion is optional.
-Standard with 4pcs A arms to fix the coil on the mandrel.
-CE mark
Model No | GL-200A | GL-300A | GL-400A | GL-500A | GL-600A |
Material thickness | 0.5-4.5mm | 0.5-4.5mm | 0.5-4.5mm | 0.5-4.5mm | 0.5-4.5mm |
Material width | 200mm | 300mm | 400mm | 500mm | 600mm |
Straightener roller | Upper 3/lower 4 | Upper 3/lower 4 | Upper 3/lower 4 | Upper 3/lower 4 | Upper 3/lower 4 |
Feeding roller | 4 sets | 4 sets | 4 sets | 4 sets | 4 sets |
Speed | 1-15m/min | 1-15m/min | 1-15m/min | 1-15m/min | 1-15m/min |
Straightening roller gap adjustment | synchronous worm gear device | synchronous worm gear device | synchronous worm gear device | synchronous worm gear device | synchronous worm gear device |
Coil I.D. | ∅450-530mm | ∅450-530mm | ∅450-530mm | ∅450-530mm | ∅450-530mm |
Coil O.D. | ∅1200mm | ∅1200mm | ∅1200mm | ∅1200mm | ∅1200mm |
Coil weight | 1000kg | 1000kg | 2000kg | 2000kg | 3000kg |
Coil press arm | optional | standard | standard | standard | standard |
Expansion method | manual | manual | manual | manual | manual |
Motor Power | 1.5kW | 1.5kW | 2.2kW | 3.75kW | 3.75kW |
Thickness | GL-200A | GL-300A | GL-400A | GL-500A | GL-600A |
0.5-1.0mm | 200 | 300 | 400 | 500 | 600 |
1.5mm | 200 | 300 | 400 | 500 | 600 |
2.0mm | 200 | 300 | 380 | 450 | 530 |
2.5mm | 200 | 250 | 300 | 380 | 430 |
3.0mm | 200 | 220 | 280 | 320 | 360 |
3.5mm | 150 | 180 | 240 | 280 | 300 |
4.0mm | 120 | 140 | 190 | 230 | 260 |
4.5mm | 90 | 100 | 140 | 190 | 200 |
