YW41 C Frame Hydraulic Press

Name: YW41 C Frame Hydraulic Press
Brand: WORLD
Rating: 5.0 (98 reviews)

C type hydraulic press with capacity range from 25tonne to 200tonne, table size and open height are customizable. The single pillar type hydraulic press is suitable for small metal parts drawing and stamping. Also suitable for sleeve parts fixing and calibration process for axis or section parts. Steel plate welded body, slide guide with pillars, independent hydraulic and electric control system.

Availability:

Quantity:



Inquire Add to Basket

Model:
YW41
Brand:
WORLD

Technical Parameters

Model		Unit	Y41-25	Y41-40	Y41-63	Y41-100	Y41-160	Y41-200
Nominal Force		kN	250	400	630	1000	1600	2000
Working table height		mm	710	710	810	800	830	900
Max.hydraulic pressure		MPa	16	25	25	25	25	25
Throat depth		mm	350	350	320	400	420	450
Stroke of slide		mm	400	400	500	600	700	700
Daylight		mm	630	630	750	800	900	1000
Speed of slide	idle	mm/s	80	80	120	100	80	80
	pressing	mm/s	18-20	18-20	18-20	15-20	10-15	10-15
	return	mm/s	75	75	100	100	70	70
Effective area of work table	L-R	mm	580	700	710	800	900	900
Effective area of work table	F-B	mm	570	570	600	700	800	800
Motor Power		KW	5.5	5.5	7.5	7.5	11	15
