Y32-160
-steel welded crown, ram and base
-high quality hydraulic cylinders
-nominal capacity: 160 ton
-table size, stroke and daylight: can be produced according to customer's request
-4 columns structure
No. | Parameter | Unit | Spec. | |
1 | Nominal Force | kN | 1600 | |
2 | Return Pressure | kN | 200 | |
3 | Max.hydraulic ic pressure | MPa | 25 | |
4 | Stroke of slide | mm | 600 | |
5 | Max. Distance from down-level of slide to work table | mm | 1000 | |
6 | Speed of slide | Empty descending | mm/s | 100 |
pressing | mm/s | 16 | ||
return | mm/s | 80 | ||
7 | Effective area of work table | L-R | mm | 1300 |
F-B | mm | 800 | ||
8 | Motor Power | KW | 11 | |
-steel welded crown, ram and base
-high quality hydraulic cylinders
-nominal capacity: 160 ton
-table size, stroke and daylight: can be produced according to customer's request
-4 columns structure
No. | Parameter | Unit | Spec. | |
1 | Nominal Force | kN | 1600 | |
2 | Return Pressure | kN | 200 | |
3 | Max.hydraulic ic pressure | MPa | 25 | |
4 | Stroke of slide | mm | 600 | |
5 | Max. Distance from down-level of slide to work table | mm | 1000 | |
6 | Speed of slide | Empty descending | mm/s | 100 |
pressing | mm/s | 16 | ||
return | mm/s | 80 | ||
7 | Effective area of work table | L-R | mm | 1300 |
F-B | mm | 800 | ||
8 | Motor Power | KW | 11 | |
