400ton H Frame Single Point Mechanical Press

400ton H frame mechanical press features

-Mono block steel plate welded body

-Eight faces ram guides with bronze plates

-Single crankshaft transmission with big gear

-PLC control with HMI, English control panel

-Wet type pneumatic clutch and brake, fricition discs are oil bath inside the flywheel.

-Safety solienoid valve to control the clutch

-Mechanical cam controller with rotary encoder

-With anti-vibration mounting pads

Standard equipment list:

PLC control

HMI with touch screen (English version)

Movable electric cabinet

Movable T-stand control button

Overload protection system

Grease central lubrication system

Pneumatic clutch and brake

Dual safety solenoid valve for clutch

Slide height adjust motor with height indicator (precision 0.1mm)

Anti-vibration pads (4pcs)

Optional accessories:

Safety light curtain

Inverter for adjustable stroke speeds

Tonnage monitor

Quick die change device (die clamps, die lifters)

Servo feeder for coil feeding

Uncoiler and straightener

3 in 1 compact feeder

Die cushion

Servo system instead of clutch (servo motor direct drive)

Shipment information:

Package type: steel pallet

Loading: one unit in a 20ft open top container

HS Code: 84626290
