TNCF4-600
WORLD
-Coil thickness: 0.5-4.5mm
-Coil width: 75-600mm
-Coil weight: 5000kg
-uncoiling machine with hydraulic coil loading trolley
-coil hold arm, with function of recoiling
Basic parameters/features | Descriptions | |
Feed width | 100-600mm | The inlet width is adjusted via high precision screw rod |
Feed length | Max 9999.99mm | Input the actual needed lengths via the HMI |
Applied thickness | 0.5-4.5mm | Straightening roll: upper 4 / lower 3, Guide roll: 2 groups, roll fabricating material adopts high alloy bearing steel, through heat treatment (tempering + high frequency treating + hard chrome plating), the rigidity and surface smoothness is assured. |
Servo motor | 3KW | Adopt servo motor and drive from YASKAWA |
Feeding accuracy | ±0.10mm | It’s though the servo motor driving the high precision planetary reducer, then drive the feeding roll via MXL, and eliminate mechanical error. At the same time, the rolls are mesh engaged via high precision gear. Gear Material adopt high alloy mold steel, grinded after high precision gear hobbing, with high precision and long service life. |
Release method | Pneumatic release (5KG/CM2) | Adopt double air cylinder. During adjustment, the air cylinder is will be ventilated, upper slide piston pushes down by cylinder pressure. When release, the cylinder release material by ascending slide piston. As quick exhaust valve is equipped the exhaust pipeline, high speed release is assured. |
Straightening adjustment | Through worm gear | Adopt 4 worm gear and worm rod for adjustment. Rotate the hand wheel to drive the worm gear, drive the upper slide lift, so as to realize the push-down amount adjustment. There are dial plates with the hand wheels, indicating the adjustment amount. |
Pass line adjustment | Electrically adjusted | There are 4 worm rod reducers equipped on the machine seat. The gear motor drive the worm rod to lift whole machine body. |
Release magnetic valve | High performance magnetic valve | |
Inlet method | Downward feed | |
Feed direction | From left to right | Can be customized |
Pass line height | 1000mm±100mm (can be customized) | |
-Coil thickness: 0.5-4.5mm
-Coil width: 75-600mm
-Coil weight: 5000kg
-uncoiling machine with hydraulic coil loading trolley
-coil hold arm, with function of recoiling
Basic parameters/features | Descriptions | |
Feed width | 100-600mm | The inlet width is adjusted via high precision screw rod |
Feed length | Max 9999.99mm | Input the actual needed lengths via the HMI |
Applied thickness | 0.5-4.5mm | Straightening roll: upper 4 / lower 3, Guide roll: 2 groups, roll fabricating material adopts high alloy bearing steel, through heat treatment (tempering + high frequency treating + hard chrome plating), the rigidity and surface smoothness is assured. |
Servo motor | 3KW | Adopt servo motor and drive from YASKAWA |
Feeding accuracy | ±0.10mm | It’s though the servo motor driving the high precision planetary reducer, then drive the feeding roll via MXL, and eliminate mechanical error. At the same time, the rolls are mesh engaged via high precision gear. Gear Material adopt high alloy mold steel, grinded after high precision gear hobbing, with high precision and long service life. |
Release method | Pneumatic release (5KG/CM2) | Adopt double air cylinder. During adjustment, the air cylinder is will be ventilated, upper slide piston pushes down by cylinder pressure. When release, the cylinder release material by ascending slide piston. As quick exhaust valve is equipped the exhaust pipeline, high speed release is assured. |
Straightening adjustment | Through worm gear | Adopt 4 worm gear and worm rod for adjustment. Rotate the hand wheel to drive the worm gear, drive the upper slide lift, so as to realize the push-down amount adjustment. There are dial plates with the hand wheels, indicating the adjustment amount. |
Pass line adjustment | Electrically adjusted | There are 4 worm rod reducers equipped on the machine seat. The gear motor drive the worm rod to lift whole machine body. |
Release magnetic valve | High performance magnetic valve | |
Inlet method | Downward feed | |
Feed direction | From left to right | Can be customized |
Pass line height | 1000mm±100mm (can be customized) | |
